Drolet Escape 1800 Wood Stove on Legs - Black Door DB03105

DroletSKU: DB03105
filler

Price:
Sale price$1,399.00

Description

Drolet Escape 1800 Wood Stove on Legs - Black Door DB03105

Heating area 500 - 2,100 Ft2
Size 26 1/8" W X 25 7/8" D X 30 1/4" H
Maximum log length 20"
Average particulate emissions rate (1) 1.54 g/h


FEATURES:

Ideal for spaces up to 2,100 ft², this large non-catalytic wood stove produces up to 75,000 BTU/h and emits only 1.54 g/h of fine particles. The unit is equipped with side panels that reduce clearances to combustible materials, and a top heat exchanger that redirects heat to the front of the unit.

Included: cast iron legs with ash drawer, top air deflector, ceramic glass, side panels, ash lip, air damper

  • Up to 8 hours burn time
  • Up to 20'' logs
  • 2.4 ft³ firebox
  • Heavy duty 5/16'' steel top
  • EPA certified
  • Proudly made in Canada
  • Limited lifetime warranty
  • Certified for mobile home and alcove installation

Options: blower, thermodisc, firescreen, fresh air intake kit

Wood stove manual | Safety notifications & general information
(PDF - 3.6 Mo)

Escape 1800 on legs - black door stove install & owner's manual
(PDF - 6.0 Mo)

Escape 1800 on legs - black door stove dimensions
(PDF - 0.5 Mo)

Government incentives may apply to this product.
LEARN MORE

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

SPECIFICATIONS:

Fuel type Dry cordwood (16" recommended)
Recommended heating area-ft² () 500 - 2,100
Overall firebox volume-ft³ 2.4
EPA loading volume-ft³ 2.02
Maximum burn time () 8 h
Maximum heat output-dry cordwood (3) 75,000 BTU/h (22 kW)
Overall heat output rate < (3) (4) 14,800 BTU/h (4.34 kW) to 28,600 BTU/h (8.38 kW)
Average overall efficiency (dry cordwood) (4) 69 % (HHV) (5) 74 % (LHV) (6)
Optimum overall efficiency (7) (8) 77 %
Optimum heat transfer efficiency (9) 75 %
Average particulate emissions rate (1) 1.54 g/h
Average CO (10) 89.4 g/h

(1) This appliance is officially tested and certified by an independent agency.

(2) Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

(3) The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(4) As measured per CSA B415.1-10 stack loss method.

(5) Higher Heating Value of the fuel.

(6) Lower Heating Value of the fuel.

(7) Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

(8) Optimum overall efficiency at a specific burn rate (LHV).

(9) The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.

(10) Carbon monoxyde.

GENERAL FEATURES:

Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 20"
Log positioning Loading over width
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 12'
Baffle type High quality vermiculite
Approved for an alcove installation Yes
Approved for a mobile home installation Yes, with fresh air intake
Shipping Weight 382 lb (173 kg)
Door type Single, glass with cast iron frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 16" X 9 1/4"
Glass air-wash system Yes
Overall dimension (Height) 30 1/4"
Overall dimension (Width) 26 1/8"
Overall dimension (Depth) 25 7/8"
Door opening – dimension (Height) 9"
Door opening - dimension (Width) 17 1/2"
Firebox – dimension (Height) 12"
Firebox – dimension (Width) 21"
Firebox – dimension (Depth) 16 1/2"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Model Legs
Adjustable threaded legs Yes
Steel thickness – body 3/16"
Steel thickness – top 5/16"
Easy-to-access ash drawer Yes
USA standard (emissions) EPA / ASTM WK47329
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S627
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime
Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)
  Canada United-States
  Single wall pipe Double wall pipe Single wall pipe Double wall pipe
Clearance – back wall 14 1/2" 6" 11" 6"
Clearance - corner 10" 7" 10" 7"
Clearance – side wall 17" 17" 16" 16"
Clearance – top (measured from the platform on which the appliance is installed)** 84" 84" 84" 84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
