Drolet Columbia II Wood Stove DB03016

DroletSKU: DB03016
filler

Price:
Sale price$1,199.00

Description

Drolet Columbia II Wood Stove DB03016

Heating area 500 - 1,800 Ft2
Size 25 5/8" W X 25 1/8" D X 29" H
Maximum log length 18"
Average particulate emissions rate (1) 1.26 g/h

FEATURES:

Of medium size, the Columbia II wood stove is ideal for heating spaces up to 1,800 ft² with a maximum heat output of 65,000 BTU/h. EPA certified at 1.26 g/h, this non-catalytic unit represents an eco-responsible heating source. The Columbia II is equipped with side panels to reduce clearances to combustible materials, as well as a top air deflector, to boost air movement through the room.

Included: cast iron legs with ash drawer, top air deflector, ceramic glass, side panels, ash lip, air damper

  • Up to 6 hours burn time
  • Up to 18'' logs
  • 1.9 ft³ firebox
  • Heavy duty 5/16'' steel top
  • EPA certified
  • Proudly made in Canada
  • Limited lifetime warranty
  • Certified for mobile home and alcove installation

Options: blower, thermodisc, firescreen, fresh air intake kit

Columbia II stove install & owner's manual
(PDF - 6.0 Mo)

Columbia II stove dimensions
(PDF - 0.7 Mo)

Government incentives may apply to this product.
LEARN MORE

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

SPECIFICATIONS:

Fuel type Dry cordwood (16" recommended)
Recommended heating area-ft² () 500 - 1,800
Overall firebox volume-ft³ 1.9
EPA loading volume-ft³ 1.44
Maximum burn time () 6 h
Maximum heat output-dry cordwood (3) 65,000 BTU/h (19 kW)
Overall heat output rate < (3) (4) 15,650 BTU/h (4.6 kW) to 23,300 BTU/h (6.83 kW)
Average overall efficiency (dry cordwood) (4) 70 % (HHV) (5) 75 % (LHV) (6)
Optimum overall efficiency (7) (8) 78 %
Optimum heat transfer efficiency (9) 74 %
Average particulate emissions rate (1) 1.26 g/h
Average CO (10) 58 g/h

(1) This appliance is officially tested and certified by an independent agency.

(2) Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

(3) The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(4) As measured per CSA B415.1-10 stack loss method.

(5) Higher Heating Value of the fuel.

(6) Lower Heating Value of the fuel.

(7) Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

(8) Optimum overall efficiency at a specific burn rate (LHV).

(9) The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.

(10) Carbon monoxyde.

General Features:

Combustion technology Non-catalytic
High-efficiency certified appliance Yes, EPA 2020 approved
Maximum log length 18"
Log positioning Loading over width
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 12'
Baffle type High quality vermiculite
Approved for an alcove installation Yes
Approved for a mobile home installation Yes, with fresh air intake
Shipping Weight 312 lb (142 kg)
Door type Single, glass with cast iron frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 15 3/4" x 9 3/4"
Glass air-wash system Yes
Overall dimension (Height) 29"
Overall dimension (Width) 25 5/8"
Overall dimension (Depth) 25 1/8"
Door opening – dimension (Height) 8"
Door opening - dimension (Width) 17 1/4"
Firebox – dimension (Height) 11 7/8"
Firebox – dimension (Width) 19 5/8"
Firebox – dimension (Depth) 13 1/2"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Model Legs
Steel thickness – body 3/16"
Steel thickness – top 5/16"
USA standard (emissions) EPA
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S627
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime
Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)
  Canada United-States
  Single wall pipe Double wall pipe Single wall pipe Double wall pipe
Clearance – back wall 14 1/2" 7 1/2" 13" 7 1/2"
Clearance - corner 12" 12" 12" 12"
Clearance – side wall 10" 10" 10" 10"
Clearance – top (measured from the platform on which the appliance is installed)** 84" 84" 84" 84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
